Door Types: Residential Roller Doors | Maximum Door Size: Up to 20m2
The smart automatic roller door opener with built-in Wi-Fi, 1000N power, and a 7 year motor warranty.
The RD1000 Pro is a smart automatic roller door opener built for reliable, quiet performance across the full range of residential roller doors. It delivers boosted 1000N pulling force, built-in F-linX Wi-Fi as standard, and an extended 7 year motor warranty. Coast to Valley Garage Doors supplies and installs the RD1000 Pro across the local area, covering everything from initial assessment and bracket configuration through to Wi-Fi app setup and handover.
Proven technology coupled with robust design, backed up by rigorous quality testing to ensure long-term reliability.
Smooth acceleration and deceleration on every cycle ensures quiet automatic operation. Particularly important when the garage sits close to bedrooms or living areas.
An integrated LED light activates automatically with each use, illuminating your garage for safe entry and exit. Stays on for 9 minutes after activation.
Effective remote operating range of up to 100 metres. Transmitter frequency: 433.92 MHz. Includes rolling code technology for added security.
An audible alert notifies you when the door is due for a service, helping you stay on top of regular maintenance before issues arise.
The RD1000 Pro delivers 1000N peak pulling force, up from 800N on the Std model. This means smoother, more reliable automatic operation across the full range of residential roller doors, including larger and heavier door configurations up to 130kg curtain weight.
The RD1000 Pro is a smart roller door opener with built-in F-linX Wi-Fi included as standard. No separate module required. Connect to your home Wi-Fi, download the app, and get live door status, remote open and close, and monitoring from anywhere. Compatible with E-Door Connect for expanded smart home integration.
The RD1000 Pro comes with a 7 year motor warranty, compared to 5 years on the Std model. Conditions apply.
The RD1000 Pro is a smart roller door opener with built-in F-linX Wi-Fi included as standard. No separate module is required. Connect to your home Wi-Fi during installation, download the app, and get full remote control of your roller door from anywhere.
App features include:
Each RD1000 Pro opener includes:
The Weight Bar is included in the Pro kit. It is not included in the RD1000 Std kit.
| Specification | Details |
|---|---|
| Max door area | 20m² |
| Max door curtain weight | 130kg |
| Max door height | 5m |
| Peak pulling force | 1000N |
| Door travel speed | Max 180mm/s |
| Opening time | Approx 21 seconds (door specific) |
| Wi-Fi | Built-in F-linX Wi-Fi (standard) |
| Transmitter frequency | 433.92 MHz |
| Security | Rolling code technology |
| Electrical input | 240V, 50Hz |
| Safety standard | AS/NZS 60335-2-95 |
| Motor warranty | 7 years (conditions apply) |
Green highlighted rows indicate Pro-exclusive specifications versus the RD1000 Std model.
Our team installs the RD1000 Pro with full site assessment, correct bracket configuration, clearance verification, and complete function testing including F-linX Wi-Fi setup, remote programming, limit setting, and safety reversal confirmation.
Minimum distance from the edge of the curtain to the edge of the door bracket: 50mm.
| Specification | Details |
|---|---|
| Max door size | 20m² |
| Min side room (edge of curtain to wall) | 105mm |
| Min side room (edge of curtain to bracket) | 50mm |
Door Type: Residential roller doors only
Max Door Size: 20m2
Max Curtain Wt: 130kg
Max Height: 5m
Pull Force: 1000N
Travel Speed: Max 180mm/s
Opening Time: Approx 21 seconds (door specific)
Wi-Fi: Built-in F-linX (no add-on required)
Power: 240V, 50Hz
Installation: Left hand or right hand
Upgrade your RD1000 Pro installation with these optional accessories, all available through Coast to Valley Garage Doors.
Pro compatibility note:
PE Beams are wireless on the RD1000 Pro (wired only on the Std). The Pro also supports E-Door Connect, which is not available on the Std model. No E-Lock is listed for the Pro roller model.
The smarter garage door controller. Unlimited connectivity anywhere and anytime. Opens up a new experience for convenience, safety, and accessibility. Compatible with the RD1000 Pro.
Keeps the door fully operational during power outages. The battery backup activates automatically when mains power is lost, so you are never locked in or out.
A wireless safety beam system that triggers automatic reversal if the beam is broken by a person, pet, or object while the door is closing. Protects your family and vehicle from contact injuries.
Available as wireless only on the RD1000 Pro
Programme multiple unique PIN codes for family members, tradespeople, or regular visitors. Provides secure keyless entry without a remote
Key ring remote transmitters are small, convenient, and can operate up to four doors from one unit. A practical addition for every set of keys in the household.
Additional wireless wall transmitters available for secondary entry points or additional garage bays. Contact us to discuss your setup requirements.
| Feature | RD1000 Std | RD1000 Pro |
|---|---|---|
| Motor warranty | 5 years | 7 years |
| Peak pulling force | 800N | 1000N |
| F-linX Wi-Fi | Optional add-on | Built-in (standard) |
| PE beams | Wired only | Wireless |
| E-Door Connect | Not available | Compatible |
| Weight bar | Not included | Included in kit |
| Max door size | 20m² | 20m² |
| Max curtain weight | 130kg | 130kg |
| Max door height | 5m | 5m |
| Travel speed | Not specified | Max 180mm/s |
| Rolling code | Yes | Yes |
| E-Lock | Compatible | Not listed |
The RD1000 Pro includes built-in F-linX Wi-Fi as standard, a 7 year motor warranty (versus 5 years on the Std), boosted 1000N pulling force (versus 800N), wireless PE Beams, E-Door Connect compatibility, and a Weight Bar in the kit. The RD1000 Std requires F-linX as a separate add-on and supports wired PE Beams only.
Yes. The RD1000 Pro is a smart roller door opener with built-in F-linX Wi-Fi included as standard. No separate module is required. Once connected to your home Wi-Fi, you can control the door, check its status, and monitor it remotely via the app.
The RD1000 Pro supports residential roller doors up to 20 square metres in area, 130kg curtain weight, and 5 metres in height. Peak pulling force is 1000N and travel speed is a maximum of 180mm per second. Opening time is approximately 21 seconds, depending on the door.
The RD1000 Pro includes a 7 year motor warranty, compared to 5 years on the RD1000 Std. Conditions apply.
Yes. PE Beams are available as wireless on the RD1000 Pro. This is different from the RD1000 Std where PE Beams are wired only.
Yes. The RD1000 Pro supports both left hand and right hand installation configurations. Minimum side room from the edge of the curtain to the wall is 105mm. Minimum distance from the edge of the curtain to the edge of the door bracket is 50mm using the direct clamping method. Our team will assess your garage setup and confirm the correct configuration before installation.
Yes. Coast to Valley Garage Doors supplies and installs the RD1000 Pro across the local service area. Installation includes door size and clearance assessment, bracket configuration, F-linX Wi-Fi app setup, remote programming, limit setting, and a full safety reversal test before handover.
Coast to Valley Garage Doors supplies and installs the RD1000 Pro roller door opener across local suburbs. For pricing, installation timeframes, or to compare the Pro and Std models, get in touch with our team.
