Door Types: Residential Sectional Doors | Maximum Door Size: Up to 15m²
Quiet belt drive performance, built-in safety, and smart app control for residential sectional garage doors.
The SD1000 is a sectional door opener engineered to the highest standard for daily residential use. It combines proven technology with high-quality features to deliver reliable, safe, and quiet operation year after year. Whether you are upgrading an existing sectional door or fitting out a new build, Coast to Valley Garage Doors provides full supply, installation, and setup across the local area.
Proven technology coupled with robust design, backed up by rigorous quality testing to ensure long-term reliability.
The SD1000 includes a 5 year motor warranty for added peace of mind. Conditions apply.
A powerful DC motor reduces noise and vibration during both opening and closing, keeping your home quiet throughout the day.
Smooth acceleration and deceleration on every cycle ensures quiet door operation. This is particularly important when the garage sits close to bedrooms or living areas.
The SD1000 uses a belt drive system for smoother, quieter operation compared to traditional chain drive openers. The belt significantly reduces vibration transferred through the ceiling and door frame, making it the preferred choice for homes where the garage sits close to bedrooms or living areas. A chain drive option is also available on request.
An integrated LED light activates automatically with each use, illuminating your garage for safe entry and exit. Stays on for 9 minutes after activation.
Effective remote operating range of up to 100 metres. Transmitter frequency: 433.92 MHz. Includes rolling code technology for added security.
An audible alert notifies you when the door is due for a service, helping you stay on top of regular maintenance before issues arise.
The SD1000 is compatible with wired PE Beams and wired E-Lock for additional safety and security. Both are available as optional add-ons.
The SD1000 pairs with the F-linX Wi-Fi system to turn your sectional garage door into a smart, app-controlled opener. Connect to your home Wi-Fi, download the app on your phone, and get full remote access from anywhere.
Wi-Fi features include:
Each SD1000 opener includes the following components:
| Specification | Details |
|---|---|
| Max door area | 15m² |
| Max door weight | 150kg |
| Max peak pulling force | 1000N |
| Max door height | 3.5m |
| Drive type | Belt drive (chain option available) |
| Transmitter frequency | 433.92 MHz |
| Security | Rolling code technology |
| Speed (opening) | 14 seconds (based on 2.3m high door) |
| Speed (closing) | 16 seconds (based on 2.3m high door) |
| Speed setting | Adjustable operating speed |
| Safety standard | AS/NZS 60335-2-95 |
| Motor warranty | 5 years (conditions apply) |
Our team installs the SD1000 with precise alignment, correct bracket clearance, and full function testing including remote programming, travel limits, and safety reversal confirmation.
| Maximum door height | Minimum operator clearance |
|---|---|
| 2.5m | 3.5m |
| 3.5m | 4.5m |
Door Type: Residential sectional doors only
Max Height: 3.5m
Max Weight: 150kg
Max Area: 15m²
Drive Type: Belt (chain option available)
Clearance: See Rail Options table above
Upgrade your SD1000 installation with these optional accessories, all available through Coast to Valley Garage Doors.
Control your door from anywhere in the world via smartphone. Connect to your home Wi-Fi, download the F-linX app, and get live door status, percentage-open monitoring, and full remote operation.
Keeps the door fully operational during power outages. The battery backup activates automatically when mains power is lost, so you are never locked in or out.
A safety beam system that triggers automatic reversal if the beam is broken by a person, pet, or object while the door is closing. Helps protect your family and vehicle.
Available as wired only.
Programme multiple unique PIN codes for family members, tradespeople, or regular visitors. Provides secure keyless entry without a remote, ideal for walks or when guests need access.
Enables remote locking and status monitoring. When the door is fully closed, the E-Lock engages automatically for an additional layer of security beyond the standard motor lock.
Available as wired only.
Additional four-channel remote transmitters are available for other household members or vehicles. Contact us to add extra remotes to your installation.
A sectional door opener is designed for sectional panel doors that open overhead in horizontal sections. A roller door opener is used for doors that roll up into a coil above the opening. The SD1000 is compatible with residential sectional doors only, up to 15 square metres in area. Coast to Valley also supplies and installs the RD1000 roller door opener for roller door applications.
The SD1000 Std comes standard with a belt drive system for quieter, smoother operation. A chain drive option is also available. Belt drive is recommended for homes where the garage shares a wall with a bedroom or living area, as it significantly reduces noise and vibration.
The SD1000 supports residential sectional doors up to 15 square metres in area, 150kg in weight, and 3.5 metres in height. Peak pulling force is 1000N. If your door falls outside these limits, contact Coast to Valley Garage Doors to discuss suitable alternatives.
Yes. The SD1000 is compatible with the optional F-linX Wi-Fi system, which allows you to control your door from anywhere using a smartphone app. You can open, close, check status, and monitor what percentage the door is open, all remotely.
The SD1000 includes a manual release lever that allows you to disengage the motor and open the door by hand during a power failure. For automatic operation without power, an optional Battery Backup add-on is available and can be included at the time of installation.
Yes. Coast to Valley Garage Doors supplies and installs the SD1000 across our local service area. Installation includes a ceiling clearance assessment, correct rail selection based on door height, remote programming, travel limit setting, and a full safety reversal test before handover.
Coast to Valley Garage Doors supplies and installs the SD1000 across local suburbs. For pricing, installation timeframes, or product support, get in touch with our team.
